Open Reduction and Internal Fixation of Mandibular Body and Parasymphyseal Fractures with Maxillomandibular Fixation and Broken Tooth Extraction
Main Text
Table of Contents
This is a case discussing a 21-year-old male who suffered from both non-comminuted mandibular parasymphyseal and body fractures as a result of a motor vehicle accident, requiring open reduction internal fixation (ORIF) without postoperative maxillomandibular fixation (MMF). The fracture was complicated by a broken tooth root, which required extraction. After intraoperative MMF, ORIF was performed. The parasymphyseal fracture was plated using two locking four-hole 2-mm thick miniplates utilizing two locking screws on either side of the fracture with one plate along the alveolar surface (monocortical screw) and one along the basal surface (bicortical screw). For the right body fracture, a three-dimensional locking ladder plate was used via a transbuccal trocar approach for additional exposure needed for proper screw placement. Once the hardware was secured, the patient was taken out of MMF and restoration of premorbid occlusion was confirmed. Lastly, watertight mucosal closure was performed using absorbable sutures and Dermabond (cyanoacrylate adhesive).
Mandible fracture; parasymphysis; symphysis, body; biomechanics; torsional; tension; compression, miniplate, lag screw, maxillomandibular fixation, MMF, intermaxillary fixation, IMF.
Fractures of the symphysis and parasymphysis comprise about 15–29% of mandibular fractures.1, 2 Mandibular body fractures generally comprise about 11–36% of all fractures. Generally, assault or motor vehicle accidents (MVAs) are the most common causes of both fracture types.3, 4 These fractures comprise a large majority of mandibular fracture cases, and this article serves to present up-to-date management strategies.
This patient was a 21-year-old male who suffered an open, displaced, and non-comminuted left parasymphyseal fracture and a closed, displaced, and non-comminuted right body fracture after MVA (Figure 1). The patient had a BMI 21, ASA 2, and no previous surgeries. Other injuries included a lumbar transverse process fracture, right pneumothorax with right rib fracture, and pulmonary contusions.
On exam, the patient was found to have an open bite deformity with trismus. There was an open gingival laceration over the left parasymphysis fracture. The patient also had posttraumatic hypoesthesia over the V3 distribution on the left side. Teeth numbers 9, 10, 21, and 22 were missing or broken.
Non-contrast CT maxillofacial scan with a three-dimensional reconstruction showed a left-sided parasymphyseal fracture and right-sided body fracture along with a left cuspid mandibular tooth (tooth #22) with a fractured root (Figure 1). Postoperative CT scans, as in this case, can confirm proper reduction and fixation (Figure 2).
Figure 1. Preoperative CT. Scans demonstrating the displaced and non-comminuted right body and displaced and non-comminuted left parasymphyseal fractures.
Figure 2. Postoperative CT. Scans demonstrating near anatomic bone reduction after ORIF of right body and left parasymphysieal fractures.
For both parasymphyseal and body fractures, open reduction and internal fixation (ORIF) is typically performed. Rarely, closed reduction may be considered with non-rigid maxillomandibular fixation (MMF) alone if there are non-displaced favorable fractures in patients who have adequate occlusion and healthy dentition.5, 6 The major disadvantage of prolonged MMF include patient discomfort, increased risk of temporomandibular joint ankylosis, inability to maintain adequate oral hygiene, and potential for airway compromise. In summary, ORIF with or without postoperative MMF offers the most reliable restoration of premorbid occlusion, bony union, and return to early function.
Treatment goals include 1) achieving bony union at fractures sites and 2) restoring premorbid occlusion. Nonunion can lead to chronic osteomyelitis and various infectious complications. Malocclusion can lead to patient discomfort as well as difficulty in mastication depending on the severity.
The patient underwent 1) intraoperative MMF, 2) dental extraction of tooth #22, 3) ORIF of both parasymphyseal and body fractures. The operative time was 1.5 hours with 110 mL of blood loss. The patient had an unremarkable postoperative course and was discharged the following day. Immediate postoperative CT scan revealed near anatomic bone reduction with adequate hardware placement, with a small fragment of retained tooth root (Figure 2). At 8 months postoperatively, the patient is currently doing well with return of normal occlusion without sign of hardware failure or infection. His preoperative V3 paresthesia resolved with the return of normal sensation. The future plan involves consideration for extraction of the remaining tooth root in a staged fashion.
In general, repair within 2 weeks is optimal if there are no other life-threatening injuries that require prioritization. Early surgery prevents the formation of tissue edema, granulation, bony calluses, or malunion. Opting for outpatient surgery with interval follow-up can help avoid unnecessary prolonged hospital stays, but there is no strong data to suggest that a delayed repair increases complication rates. However, it is worth noting that delayed repair may lead to more technical challenges, as indicated by prolonged surgical times in certain studies.7–10 It is best to avoid delaying repair beyond 2 weeks due to early bony union between displaced segments. Removal of newly formed callus and granulation between displaced fracture sites can increase surgical difficulty. Sometimes, osteotomies are performed to remove segments of bony union with gross bony displacement resulting in malocclusion.
Prior to the case, surgical airway management should be discussed with the anesthesia team.
For patients who have sustained isolated mandible fractures, the airway is secured via the nasotracheal route to allow for restoration of premorbid occlusion with intraoperative MMF and intraoral manipulation. In patients with concurrent midface or LeFort fractures with medial buttress fractures that may require rigid fixation, one may consider submental intubation or tracheostomy for airway control. Submental intubation offers superior cosmesis in young patients by avoiding a tracheostomy scar and potentially a prolonged intensive care unit stay (Figure 3). Passing the endotracheal tube can be challenging in patients with significant floor of mouth or tongue edema or those with poor cardiopulmonary reserve. In such patients, it may be safer to consider tracheostomy instead.
Figure 3. Submental Intubation. Left picture demonstrates intraoperative usage of submental intubation to allow for LeFort with medial buttress involvement and mandible fracture repairs. Right picture demonstrates the cosmetically optimal thin scar along the submental region that is well camouflaged.
Betadine paint is applied intraorally and externally on the bilateral face and neck to prepare for any unforeseen external approaches. Usually, an intraoral vestibular approach provides adequate access to the symphysis, parasymphysis, and body fractures. Additional external transbuccal approaches using the trochar may be necessary to improve exposure for fractures located in the posterior body, angle, and subcondylar regions. External approaches are typically reserved for subcondylar fractures requiring open repair using a Risdon incision for instance, or when a reconstruction plate is being applied for comminuted or severely displaced fractures.
Prior to making incisions, lidocaine with epinephrine injections are used to promote hemostasis and hydrodissection of soft tissue away from the bone. In this particular case, local was not injected initially while assessing viability of the mucosa surrounding the open fracture site in case mucosal debridement is required to achieve reliable mucosal closure. Once we have determined that mucosa bleeds appropriately and no mucosa or soft tissue debridement is required, we then injected local to enhance hemostasis.
The first step is obtaining adequate exposure of all the fractures. A vestibular incision is made into a subperiosteal tissue plane over the left parasymphyseal region, with care to maintain around 2–3 mm of mucosal cuff for watertight closure at the conclusion of the case. The subperiosteal dissection is carried out all the way down to the inferior border of the mandible using a periosteal elevator. The inferior border of the mandible and the bony alignment along the fracture line serves as visual references for proper reduction.
For the mandibular body fracture, the vestibular incision may be extended posteriorly towards the angle. Excess mucosal overhang (wider than 2–3 mm from dentition) in this area should be avoided to optimize fracture and hardware visualization. Subperiosteal dissection is again carried down to the inferior border of the mandible and, if necessary, the posterior border of the mandible, as these borders serve as visual references for bone reduction.
In exposing either a parasymphyseal or body fracture, one must be mindful of the mental nerve, a terminal branch of the inferior alveolar nerve (cranial nerve V3). It provides sensory innervation to the ipsilateral lower face, lower lip, and mandibular teeth. The mental foramen is a weak region prone to fracture and is typically located between the first and second premolar teeth.11 The nerve can be injured during submucosal dissection. In situations with difficulty in identifying the nerve, the mental foramen should first be identified by dissecting in the subperiosteal tissue plane near midline to out laterally. Once the mental foramen is identified, the mental nerve can be followed more distally to perform safe submucosal dissection without injuring the nerve.
Once all the fractures are exposed, dental extraction and bone debridement is performed, if indicated. In cases involving bony fragments, loose pieces of bone that are not attached to the periosteum are removed down to healthy bleeding bone. If damaged dentition or alveolar fractures are encountered, consultation with an oral maxillofacial surgery team can aid in the decision to remove damaged teeth intraoperatively or consider dental rehabilitation. In this particular case, the tooth root was fractured and was assessed to be nonviable. Tooth extraction was performed to prevent delayed odontogenic infection that can lead to future hardware infection. A major downside of tooth extraction is that it leaves a gap in the bone, which can contribute to structural instability, especially with multiple adjacent fractures.
Next, MMF was performed to restore premorbid occlusion. In this case, intermaxillary fixation (IMF) screws were used to enable temporary, intraoperative fixation to maintain preoperative occlusion during open reduction. When placing IMF screws, tooth roots must be avoided by assuming that the dental root length is approximately twice the crown height with IMF screws placed in between expected tooth roots. An advantage of using a manual torque screwdriver as opposed to using a power-driven screwdriver for IMF screws is that the operator is provided with increased tactile feedback if tooth roots are inadvertently encountered during screw placement. If this occurs, the direction of screw placement can be adjusted to avoid injury.
Next, ORIF is performed starting with the fracture that is most easily reducible providing easier visualization and less comminution. Fractures within a dentate segment should always be fixated first. If multiple dentate segment fractures are present, the least comminuted or most anterior fracture should be fixated first. Anterior mandible fractures, such as parasymphyseal fractures, are generally easier to plate than body, angle, or subcondylar fractures. The reason for starting with rigid fixation of an easier fracture is that any errors in bone reduction from the first fracture repair will result in compounding bone reduction error in subsequent fracture sites and cause malocclusion.
In this case, the left parasymphyseal fracture was addressed first. Bone reduction was further refined by compressing the fractures against each other using bone reduction forceps. During this process, the inferior border of the mandible and premorbid occlusion is used to confirm proper bone reduction. In this specific case, the fracture was plated using two locking four-hole 1-mm profile miniplates utilizing two locking screws on either side of the fracture with one plate along the alveolar surface (monocortical screws) and one along the basal surface (bicortical screws). Using depth gauges, the proper length of the bicortical screws can be measured for the inferior border plate.
After proper reduction and fixation of the parasymphyseal fracture, the right body fracture was approached. In this case, to counteract the torsional forces for the body fracture, a three-dimensional locking ladder plate was used.12 Alternatively, one can place two separate miniplates. The advantage of a three-dimensional ladder plate is the additional stability between the inferior and superior plates, which are fused. This facilitates placement of two separate plates in poorly visualized areas (such as posterior body or angle fractures). A third option includes the use of a load bearing reconstruction plate at the inferior border of the body fracture, which is strong enough to resist both compressive and splaying forces, with or without an arch bar. In this case, because of the additional exposure needed for proper screw placement, a transbuccal trocar approach was used. During the trocar placement, a small skin incision is made parallel to the path of any facial nerve branches right over the center of the plate, and a blunt instrument is used to dissect intraorally. Once the hardware was secured, the patient was taken out of MMF, and restoration of premorbid occlusion was confirmed.
Lastly, watertight mucosal closure was performed. To prevent hardware infection, saliva exposure should be minimized. In cases with significant mucosal laceration or poor tissue quality, sutures can be looped around the tooth along the lingual aspect to provide a stronger anchoring suture and to avoid the incision dehiscing from buccal traction. Prior to closure, copious intraoral irrigation with Betadine paint and normal saline is performed. Deeper structures including the mentalis muscle, which is the only elevator of the lower lip and chin, should be resuspended to prevent long-term chin ptosis.9, 13 Resuspending the deeper structures also provides an additional vascularized layer to decrease the risk of hardware extrusion and wound breakdown. Mucosa is then closed with absorbable sutures, such as interrupted Vicryl in this case. To improve the watertight closure, Dermabond (cyanoacrylate adhesive) is often used by the senior author (TL) to seal the mucosal wound, acting as a suture adjunct while providing bacteriostatic and hemostatic properties.14–16
This case represents a relatively common type of facial trauma. In this section, we will discuss key concepts that influenced the treatment plan for this particular patient. Firstly, we will discuss the biomechanics of mandible fractures that are unique to each subsite and demonstrate commonly utilized plate configurations for these fracture sites. Understanding predominant bone displacement patterns unique to each fracture site will determine the optimal hardware configuration.
A parasymphyseal fracture is any fracture that spans from canine to canine. Based on biomechanical studies, a common bony displacement pattern that occurs at the parasymphysis or symphysis is that the basal (inferior) border of the mandible widens, while the alveolar (superior) border of the mandible compresses (Figure 4A).17 As such, during ORIF, the inferior border plate is prioritized, as it provides most of the structural stability to counteract splaying forces. One can provide additional stability by using a thicker, load bearing plate or using a plate with additional screw holes.18–20
Figure 4A. Biomechanics of Symphyseal fractures. With incisor loading, there is a tendency for the inferior border of the mandible to widen while the superior border of the mandible will compress.
Figure 4B. Parasymphysis Plating Configuration. The emphasis is placed on plating along the inferior border plate. One can consider using two miniplates (1-mm thickness profile) with the inferior border plate being a 6-hole plate instead of 4-hole plate if additional stability is desired.
Figure 4C. Parasymphysis Plating Configuration. Alternatively, a thicker (2-mm thickness profile) single inferior border plate can be used with an arch bar that acts as a tension band, which provides added stability along the superior border of the mandible.
Contrastingly, angle fractures with incisor loading forces tend to cause widening along the alveolar border and compression at the basal border (Figure 5A). The idea behind the Champy plate is that it provides sufficient stability by plating against splaying forces along the superior border alone. However, with molar loading at the angle, there is an opposite tendency along the basal border to widen, while the alveolar border compresses (Figure 5B).17 A biomechanical study by Abraha et al. compared the use of a single alveolar border plate (Champy fixation) to biplanar fixation with a second inferior border plate during a simulation of angle fracture repairs, and found that the biplanar fixation technique provided superior stability.21, Similarly, Alkan et al. found that 3D curved angle strut plate provided more favorable biomechanical stability than the Champy plate but was not significantly different than the biplanar plate placement.12 For angle fractures, the senior author (TL), therefore, prefers the use of a three-dimensional plate with 5 or 6 holes along the superior border plate and 4 holes along the inferior border plate, placed through a transbuccal trocar approach (Figure 5C).
Figure 5A. Angle Fracture Biomechanics with Incisor Loading. Incisive loading results in splaying forces along the superior border and compression along the inferior border.
Figure 5B. Angle Fracture Biomechanics with Molar Loading. Molar loading results in compression along the superior border, while the inferior border will widen.
Figure 5C. Angle Plate Configuration. This shows the use of a three-dimensional ladder plate, which links the alveolar and basal plates.
The mandibular body is a transition zone between the mandibular angle and parasymphysis. As such, torsional forces predominate in this region along with either inferior or superior border displacement dictated by how anterior or posterior the loading forces are located (Figure 6A).17 Biomechanical studies looking at plate configuration recommend stabilizing a body fracture with two plates instead of a single plate to address the torsional displacement that can occur in this region.22 The senior author (TL) prefers placement of two miniplates or a three-dimensional plate for body fractures (Figure 6B). An alternative plating configuration used by the senior author (DH) is to place one thicker plate at the inferior border along with an arch bar on the mandibular dentition to compress the alveolar aspect of the fracture, resisting both compressive and splaying forces (Figure 6C). This offers the advantage of avoiding screw placement of the alveolar plate, which can potentially injure teeth roots. There is also a decreased risk of alveolar plate exposure secondary to wound dehiscence.
Figure 6A. Mandibular body fracture. Body fractures experience compression along the inferior/basal border with splaying at the alveolar border. These are additional opposing torsional forces on the segments anterior and posterior to the fracture line.
Figure 6B. Body Fracture Plating. Configuration using two miniplates.
Figure 6C. Body Fracture Plating. Configuration using a single thicker inferior border plate and arch bar on the mandibular dentition.
Once a surgeon is familiar with the biomechanics of individual fracture sites, selecting the right type of hardware is crucial for overall success of the surgery. For non-comminuted fractures with adequate bone stock present on both sides of the fracture line, miniplates have become a standard method of providing ORIF. These are considered a load-sharing type of hardware, which means the load is shared between the hardware and the bone during the bone healing process.
However, for comminuted fractures or segmental bony defects with inadequate bone stock present on either side of the fracture line, a load bearing type of plate is used, which is commonly referred to as a reconstruction plate. With the load bearing type of hardware, the entire force of loads is withstood by the hardware.
In the setting of craniofacial trauma, when compared to outdated compression plates, miniplates offer improved bone adaptability without needing bicortical screw fixation. This promotes semi-rigid fixation (load-sharing), leading to improved cortical bone perfusion and the formation of appropriate bony callus during healing.23
Miniplates come with either locking or non-locking versions. Locking miniplates minimize movement between the plate and bone by securing the screw head threads to a threaded plate. During tightening, this stabilizes bony segments without pulling them toward the plate and reduces the risk of bone necrosis that can occur from excessive compression on the bone surface. A major advantage is that locking plates provide adequate rigid fixation even with suboptimal plate adaptation with margins of error ranging from 0–3 mm of plate offset from the bone surface. Non-locking plates on the other hand show significant weakening (yield load, yield displacement and stiffness) even with 1 mm of plate offset.24 The screw should ideally be tightened perpendicular to the plate; however, most modern locking hardware systems tolerate up to 10–30 degrees of deviation depending on the manufacturer.6 A drawback is potentially increased hardware cost as locking screws typically cost more than nonlocking screws. However, the increase in hardware cost may be neutralized by a decrease in operative time related cost. Another disadvantage to the locking system is a loss of tactile feedback of the screw tightening into bone, which is only provided by the torque felt from the screw locking directly onto the plate.
Non-locking systems differ in mechanism by securing the plate flush against the bone. This tightening capability poses a theoretical risk of reducing blood supply to the underlying bone which can lead to bone necrosis and premature hardware failure. Precise adaptation of the plate onto the bone contact surface is mandatory to prevent improper fixation caused by minor force transfers.9, 20, 24, 25 This tends to result in longer operative times spent on achieving perfect plate adaption and may create a significant challenge in subcondylar and angle fractures where visualization and surgical access are limited. Systematic reviews comparing plates of the same dimensions, fixation principles, and design have demonstrated that in the short term, locking plates required fewer instances of postoperative MMF fixation, but yield similar overall complication rates.6, 9, 20, 2529 Although the senior author (TL) generally prefers to use a locking system for the vast majority of his cases, each case should be tailored, considering cost and ease of placement in line with the surgeon's expertise and preference.
The biomechanics of screw placement and fracture stability dictates the total number of screws that should be placed. Generally, 4-hole plates with 2 screws on either side of a fracture is adequate for non-comminuted fractures with sufficiently healthy bone stock. However, 6-hole plates with 3 screws on either side of the fracture provide significantly greater structural stability.30 A biomechanical study by Haug et al demonstrated that using three screws on either side of the fracture line provides significantly more stability than using two screws on either side. However, using 4 screws on either side of the fracture line provides marginally improved stability when compared to using 3 screws on either side.30 Therefore, 3 screws on either side of the fracture line should be utilized for less stable fractures requiring additional support.
Conventional practice dictates the use of monocortical screws at the alveolar border to prevent inadvertent injury to dental roots and the inferior alveolar nerve. It is important to remember that there is an inherent risk of injury to these structures from drilling alone.18 Tooth roots, particularly in the body region, are in close proximity to the buccal (outer) cortical bone, typically around 2–2.5 mm in depth.31 Bicortical fixation on the other hand provides theoretically improved stability to facilitate healing, however, carries potential risks of inadvertent tooth root and inferior alveolar nerve injury. Biomechanical models indicate that both monocortical and bicortical screws can achieve and maintain adequate bony reduction without significant differences in mandibular displacement from both incisor and molar loading.23 Ultimately, the decision should be based on surgeon discretion and evaluation of whether bicortical screws can be safely employed in specific instances.
Another method of rigid fixation includes the use of lag screws, particularly in bony fragments that have cortical overlap or oblique orientations.6 This was popularized in 1976 for use in non-comminuted parasymphyseal fractures without significant gaps.6, 31, 32 These screws contain threads that engage only in the distal bone fragment, compressing bone between distal segment and screw head. The lag screw technique was shown to have slight superiority compared to the other fixation methods to resist force loading at the molar teeth.6, 19, 33, 34 Either 1 single lag screw with an arch bar or 2 lag screws without MMF can be a good way to secure anterior mandibular fractures.31-33 Nonetheless, placing lag screws perpendicular to fracture lines is technically challenging and relies on screw availability and surgeon expertise, making them less commonly employed.
Another alternative for fracture repair involves using a thicker reconstruction plate for its “load bearing” capacity.6, 35 Reconstruction plating is used in comminuted fractures and segmental bony defects. These plates remove extrinsic forces that act on the bone at tension zones, where fragment separation occurs. Biomechanical studies indicate that reconstruction plates match lag screws in resisting torsional loads, outperforming ladder plates and parallel miniplates.18, 19, 34 This thicker plate may be superior to using 2 separate miniplates for elderly or female patients with shorter mandibular vertical heights or atrophic mandibles.18 Its placement, however, can be cumbersome and costly, and in most other instances, adequate stability can be achieved through the use of 2 biplanar miniplates in non-comminuted fractures. In clinical practice, its use is mainly indicated for significant mandibular defects, comminuted fractures with poor bone stock, presence of severe osteomyelitis, or segmental mandibular defects necessitating the use of their load bearing properties.6
In summary, the ideal plate configuration for parasymphysis and body fractures should be based on the biomechanics of the fracture sites as well as patient related variables. For non-comminuted parasymphyseal fractures, using either 2 or 3 screws on either side of the fracture line with miniplates is acceptable. For parasymphyseal fractures, the inferior border plate is considered more important and some authors have recommended using a single, thicker inferior plate as opposed to 2 miniplates.18 Other valid repair options include the use of lag screws. For body fractures, the key is to resist torsional forces. Using either a single three-dimensional plate versus 2 separate miniplates along the inferior and superior mandibular borders have been demonstrated to provide similar outcomes and stability. Alternatively, an arch bar can substitute for the superior plate in parasymphyseal, body, or angle fractures to minimize superior plate related complications. Finally, a single, thicker inferior plate is a traditional and time-tested approach, especially if postoperative MMF fixation is performed concurrently.18
The management of teeth along a fracture line can be challenging. Any involved teeth that are not extracted have the potential to undergo necrosis, particularly in the presence of chronic infections, which can lead to nonunion. Conversely, extracting any teeth can lead to structural instability within the remaining mandible. The senior authors advocate for a more conservative approach, emphasizing the salvage potential of viable teeth through endodontic treatments and prophylactic antibiotics. Vertical root fractures and horizontal fractures near the crown are less favorable for future endodontic care, and extraction should be considered.
In our case, the patient's tooth root was split in half, minimizing the chance of future restoration. Following consultation with an oral-maxillofacial surgeon, the tooth root was extracted. Indications for tooth removal include severe periodontal disease, unrestorable crowns, vertical root fractures, or any misaligned teeth that interfere with proper mandibular reduction.2, 9, 37
In this particular case, only temporary MMF intraoperatively was utilized for bone reduction, in line with conventional surgical management. The use of postoperative MMF has also been a standard treatment protocol and its efficacy in promoting bone union is uncontested. However, routine postoperative MMF comes with inherent risks including airway compromise, gingival injury, temporomandibular joint immobility or ankylosis, difficulty with oral hygiene, and patient non-compliance or dissatisfaction. A study by Saman et al. analyzed 413 mandible fractures (non-comminuted symphyseal, parasymphyseal, or angle fractures). Among the patients, 54% were treated with postoperative MMF, while the remaining 46% were not. The study found no significant differences in wound dehiscence, infection, plate removal, nonunion, malunion, and malocclusion, supporting selective usage of postoperative MMF in line with current retrospective studies.
Postoperative MMF may be beneficial for severely comminuted or segmental mandibular defects. Rigid MMF followed by elastics can also maintain proper occlusion during healing for minimally-displaced subcondylar fractures or condylar head fractures not amenable to screw placement. Patients with true condylar head or intracapsular fractures should ideally be placed in MMF for the shortest time frame allowable to achieve premorbid occlusion.39 Similarly, patients who have residual minor occlusal discrepancies may also benefit from a short period (1–2 weeks) of MMF to allow for healing.38, 40, 41 MMF is not recommended for patients who are non-compliant, psychiatrically or neurologically obtunded, or have seizure or nausea and vomiting disorders, severe airway or pulmonary disease, or intellectual disability.42
Stryker craniofacial mandible plating set.
Nothing to disclose.
The patient referred to in this video article has given their informed consent to be filmed and is aware that information and images will be published online.
Citations
- Motamedi MH. An assessment of maxillofacial fractures: a 5-year study of 237 patients. J Oral Maxillofac Surg. Jan 2003;61(1):61-4. doi:10.1053/joms.2003.50049.
- Rahpeyma A, Khajehahmadi S, Abdollahpour S. Mandibular symphyseal/parasymphyseal fracture with incisor tooth loss: preventing lower arch constriction. Craniomaxillofac Trauma Reconstr. Mar 2016;9(1):15-9. doi:10.1055/s-0035-1551542.
- King RE, Scianna JM, Petruzzelli GJ. Mandible fracture patterns: a suburban trauma center experience. Am J Otolaryngol. Sep-Oct 2004;25(5):301-7. doi:10.1016/j.amjoto.2004.03.001.
- Koshy JC, Feldman EM, Chike-Obi CJ, Bullocks JM. Pearls of mandibular trauma management. Semin Plast Surg. Nov 2010;24(4):357-74. doi:10.1055/s-0030-1269765.
- Jain P, Rathee M. Mandible Body Fracture. [Updated 2023 Apr 10]. In: StatPearls [Internet]. Treasure Island (FL): StatPearls Publishing; 2023 Jan-. Available from: https://www.ncbi.nlm.nih.gov/books/NBK553119/.
- A. Y. Principles of Internal Fixation in Maxillofacial Surgery. In: Bonanthaya K, Panneerselvam E, Manuel S, Kumar VV, Rai A, eds. Oral and Maxillofacial Surgery for the Clinician. Springer Nature; 2021.
- Barker DA, Park SS. Is fixation of mandible fractures urgent? Laryngoscope. May 2011;121(5):906-7. doi:10.1002/lary.21777.
- James J, Farrell Tt, Stevens M, Looney S, Faigen A, Anderson J. Time to open repair of mandibular fractures and associated complications. J Oral Maxillofac Surg. Jan 2020;78(1):101-107. doi:10.1016/j.joms.2019.09.009.
- Perez D, Ellis E III. Complications of mandibular fracture repair and secondary reconstruction. Semin Plast Surg. Nov 2020;34(4):225-231. doi:10.1055/s-0040-1721758.
- Webb LS, Makhijani S, Khanna M, et al. A comparison of outcomes between immediate and delayed repair of mandibular fractures. Can J Plast Surg. Winter 2009;17(4):124-6. doi:10.1177/229255030901700401.
- Loyal PK, Butt F, Ogeng'o JA. Branching pattern of the extraosseous mental nerve in a kenyan population. Craniomaxillofac Trauma Reconstr. Dec 2013;6(4):251-6. doi:10.1055/s-0033-1356756.
- Alkan A, Celebi N, Ozden B, et al. Biomechanical comparison of different plating techniques in repair of mandibular angle fractures. Oral Surg Oral Med Oral Pathol Oral Radiol Endod. 2007;104(6):752-6.
- Shah A, Patel A, Steinbacher D. Soft tissue coverage for mandibular fractures using two miniplates. Craniomaxillofac Trauma Reconstr. Dec 2012;5(4):253-4. doi:10.1055/s-0032-1329543.
- Borie E, Rosas E, Kuramochi G, Etcheberry S, Olate S, Weber B. Oral applications of cyanoacrylate adhesives: a literature review. Biomed Res Int. 2019;2019:8217602. doi:10.1155/2019/8217602.
- Kazzi MG, Silverberg M. Pediatric tongue laceration repair using 2-octyl cyanoacrylate (dermabond((R))). J Emerg Med. Dec 2013;45(6):846-8. doi:10.1016/j.jemermed.2013.05.004.
- Sagar P, Prasad K, Lalitha RM, Ranganath K. Cyanoacrylate for intraoral wound closure: a possibility? Int J Biomater. 2015;2015:165428. doi:10.1155/2015/165428.
- Tams J, van Loon JP, Otten E, Rozema FR, Bos RR. A three-dimensional study of bending and torsion moments for different fracture sites in the mandible: an in vitro study. Int J Oral Maxillofac Surg. Oct 1997;26(5):383-8. doi:10.1016/s0901-5027(97)80803-x.
- Ellis E, 3rd. A study of 2 bone plating methods for fractures of the mandibular symphysis/body. J Oral Maxillofac Surg. Jul 2011;69(7):1978-87. doi:10.1016/j.joms.2011.01.032.
- Madsen MJ, McDaniel CA, Haug RH. A biomechanical evaluation of plating techniques used for reconstructing mandibular symphysis/parasymphysis fractures. J Oral Maxillofac Surg. Oct 2008;66(10):2012-9. doi:10.1016/j.joms.2008.06.013.
- Lee T, Sawhney R, Ducic Y. Miniplate fixation of fractures of the symphyseal and parasymphyseal regions of the mandible: a review of 218 patients. JAMA Facial Plast Surg. Mar 1 2013;15(2):121-5. doi:10.1001/jamafacial.2013.307.
- Mehari Abraha H, Iriarte-Diaz J, Reid RR, Ross CF, Panagiotopoulou O. Fracture fixation technique and chewing side impact jaw mechanics in mandible fracture repair. JBMR Plus. Jan 2022;6(1):e10559. doi:10.1002/jbm4.10559.
- De Medeiros RC, de Moura AL, Sawazaki R, et al. Comparative in vitro mechanical evaluation of technique using a 2.0 mm locking fixation system for simulated fractures of the mandibular body. J Craniomaxillofac Surg. 2015 Apr;43(3):302-5. doi:10.1016/j.jcms.2014.11.012.
- Joshi U, Kurakar M. Assessment of lingual stability in mandible fracture: monocortical versus bicortical fixation using FEM analysis. J Maxillofac Oral Surg. Dec 2018;17(4):514-519. doi:10.1007/s12663-017-1073-0.
- Haug RH, Street CC, Goltz M. Does plate adaptation affect stability? A biomechanical comparison of locking and nonlocking plates. J Oral Maxillofac Surg. Nov 2002;60(11):1319-26. doi:10.1053/joms.2002.35732.
- Harjani B, Singh RK, Pal US, Singh G. Locking v/s non-locking reconstruction plates in mandibular reconstruction. Natl J Maxillofac Surg. Jul 2012;3(2):159-65. doi:10.4103/0975-5950.111371.
- Batbayar EO, Dijkstra PU, Bos RRM, van Minnen B. Complications of locking and non-locking plate systems in mandibular fractures. Int J Oral Maxillofac Surg. Sep 2019;48(9):1213-1226. doi:10.1016/j.ijom.2019.02.019.
- Collins CP, Pirinjian-Leonard G, Tolas A, Alcalde R. A prospective randomized clinical trial comparing 2.0-mm locking plates to 2.0-mm standard plates in treatment of mandible fractures. J Oral Maxillofac Surg. Nov 2004;62(11):1392-5. doi:10.1016/j.joms.2004.04.020.
- Herford AS, Ellis E III. Use of a locking reconstruction bone plate/screw system for mandibular surgery. J Oral Maxillofac Surg. Nov 1998;56(11):1261-5. doi:10.1016/s0278-2391(98)90605-x.
- Sarkar DF, Mishra N, Samal D, et al. Locking versus non-locking plating system in the treatment of mandibular fractures: a randomized comparative study. J Craniomaxillofac Surg. Mar 2021;49(3):184-190. doi:10.1016/j.jcms.2021.01.006.
- Haug RH. The effects of screw number and length on two methods of tension band plating. J Oral Maxillofac Surg. Feb 1993;51(2):159-62. doi:10.1016/s0278-2391(10)80015-1.
- Al-Jandan BA, Al-Sulaiman AA, Marei HF, Syed FA, Almana M. Thickness of buccal bone in the mandible and its clinical significance in mono-cortical screws placement. A CBCT analysis. Int J Oral Maxillofac Surg. Jan 2013;42(1):77-81. doi:10.1016/j.ijom.2012.06.009.
- Niederdellmann H, Schilli W, Duker J, Akuamoa-Boateng E. Osteosynthesis of mandibular fractures using lag screws. Int J Oral Surg. Jun 1976;5(3):117-21. doi:10.1016/s0300-9785(76)80059-2.
- Ellis E III, Ghali GE. Lag screw fixation of anterior mandibular fractures. J Oral Maxillofac Surg. Jan 1991;49(1):13-21; discussion 21-2. doi:10.1016/0278-2391(91)90259-o.
- Emam HA, Stevens MR. Can an arch bar replace a second lag screw in management of anterior mandibular fractures? J Oral Maxillofac Surg. Feb 2012;70(2):378-83. doi:10.1016/j.joms.2011.08.010.
- Richardson M, Hayes J, Jordan JR, Puckett A, Fort M. Biomechanical evaluation of a mandibular spanning plate technique compared to standard plating techniques to treat mandibular symphyseal fractures. Surg Res Pract. 2015;2015:569030. doi:10.1155/2015/569030.
- Coletti DP, Caccamese JF Jr, Norby C, Edwards S, von Fraunhofer JA. Comparative analysis of the threaded and tapered locking reconstruction plates. J Oral Maxillofac Surg. Dec 2007;65(12):2587-93. doi:10.1016/j.joms.2006.05.054.
- Kumar PP, Sridhar BS, Palle R, Singh N, Singamaneni VK, Rajesh P. Prognosis of teeth in the line of mandibular fractures. J Pharm Bioallied Sci. Jul 2014;6(Suppl 1):S97-S100. doi:10.4103/0975-7406.137397.
- Spinnato G, Alberto PL. Teeth in the line of mandibular fractures. Atlas Oral Maxillofac Surg Clin North Am. Mar 2009;17(1):15-8. doi:10.1016/j.cxom.2008.10.006.
- Saman M, Kadakia S, Ducic Y. Postoperative maxillomandibular fixation after open reduction of mandible fractures. JAMA Facial Plast Surg. Nov-Dec 2014;16(6):410-3. doi:10.1001/jamafacial.2014.543.
- Kumar I, Singh V, Bhagol A, Goel M, Gandhi S. Supplemental maxillomandibular fixation with miniplate osteosynthesis-required or not? Oral Maxillofac Surg. Mar 2011;15(1):27-30. doi:10.1007/s10006-010-0229-6.
- Park JM, Jang YW, Kim SG, et al. Comparative study of the prognosis of an extracorporeal reduction and a closed treatment in mandibular condyle head and/or neck fractures. J Oral Maxillofac Surg. Dec 2010;68(12):2986-93. doi:10.1016/j.joms.2010.02.034.
- Chritah A, Lazow SK, Berger JR. Transoral 2.0-mm locking miniplate fixation of mandibular fractures plus 1 week of maxillomandibular fixation: a prospective study. J Oral Maxillofac Surg. Dec 2005;63(12):1737-41. doi:10.1016/j.joms.2005.08.022.
- Ezhilarasi SKR. IMF After ORIF in maxillofacial fractures—case report and literature review. The Traumaxilla. 2022;4:1-3. doi:10.1177/26323273211073785.
- Cornelius CP, Ehrenfeld M. The use of MMF screws: surgical technique, indications, contraindications, and common problems in review of the literature. Craniomaxillofac Trauma Reconstr. Jun 2010;3(2):55-80. doi:10.1055/s-0030-1254376.
Cite this article
Sheen D, Yu C, Debs S, Kwak P, Vahidi N, Hawkins D, Lee T. Open reduction and internal fixation of mandibular body and parasymphyseal fractures with maxillomandibular fixation and broken tooth extraction. J Med Insight. 2024;2024(414). doi:10.24296/jomi/414.
Procedure Outline
Table of Contents
- 1. Introduction
- 2. Surgical Preparation and Approach
- 3. Exposure of Fracture Sites
- 4. Remove Remaining Tooth Root with FG 702 Drill Bit
- 5. Maxillomandibular Fixation with IMF Screws to Restore Premorbid Occlusion
- 6. ORIF
- 7. Release Maxillomandibular Fixation
- 8. Final Inspection of Occlusion
- 9. Closure
- 10. Post-op Remarks
- Prep and Drape Patient
- Surgical Approach
- Parasymphyseal Fracture
- Body Fracture
- Parasymphyseal Fracture
- Body Fracture
- Suction Blood from Stomach with NG Tube
Transcription
CHAPTER 1
Hi, I am Dr. Thomas Lee from Virginia Commonwealth University. Today, I'd like to discuss a patient who had a motor vehicle accident and suffered a mandible fracture. We'll start out by discussing patient's CT imaging. So this particular patient you can see has a fracture involving the parasymphysis and what's interesting is this particular patient does have canine fracture that has split across and this will be addressed during surgery. Similarly, on the opposite side, patient has a body fracture. In this case, the outer cortex is in two separate fracture segments. So you have one, two, and three segment piece with two inner cortex that's involved. And this also will require reduction and fixation. And because it's telescoped with this middle piece, I anticipate this being more difficult to reduce, especially because it's in three pieces. Here you can see the canine with the roots present, but the crown is gone, with the parasymphysis fracture and the body fracture starting here with the telescoped middle piece. And here is your 3D reconstruction, showing what we just discussed, parasymphysis fracture and the body fracture. The key surgical steps involve putting the patient to sleep using nasotracheal intubation. This way the endotracheal tube will not interfere with restoring patient's premorbid occlusion. Once patient's asleep, we'll start with the prepping and draping in a sterile fashion. The first step with the surgery involves exposing the fracture site for the both parasymphysis and the body fracture will begin with intraoral incision. Once both fracture sites's exposed, I'll generally focus on the easier fracture, in this case, is the parasymphysis fracture site. Now this area, to my surprise, had a fracture involving the tooth roots. In consultation with the oral maxillofacial surgeons, they recommended that we proceed with extraction of the tooth. In this case, we used drill to remove remaining tooth roots. Unfortunately, they were not available to come in, so this was the best option that we had at the time. Once the tooth root was addressed involving the parasymphysis, we then focused on bringing the patient into proper bony reduction. We performed maxillomandibular fixation using IMF screws, bringing patient into premorbid occlusion. Once patient was in rigid MMF, we then proceeded with fixation process. For the parasymphysis, we used mini plates with mono cortical screws along the top and bicortical screws along the inferior plate. For the body fracture site, we used a hybrid plate that has essentially two plates that are fused side by side. The benefit of this is that you have both superior and inferior plate in a very limited space. And we were able to fixate this area once it was properly reduced. For the anterior screws, we were able to place screws through the intraoral approach. For the posterior area, we had to use transbuccal trocar approach to place the screws in a proper alignment. Once the body fracture was properly fixated, we then proceeded with closing. Because patient has significant mucosal injuries, our goal was to perform watertight closing of the mucosal lacerations. Once that was completed, we emptied out gastric content to ensure the patient does not vomit from any blood that the patient may have swallowed. And at that point we had concluded the procedure and patient was safely extubated.
CHAPTER 2
So the way we're gonna position the patient, we usually turn 90 degrees away from the anesthesia. We go past 90. So we'll have access through all three sides. And I generally will always also almost always prefer to do nasotracheal intubation like this with a tape at the top to secure it to prevent it from coming out. And I generally use paint and I'll actually dunk this in the mouth 'cause we want to make sure mouth gets sterilized as much as possible. And we will prep the whole face out. And especially for a patient like this, we have bilateral fracture. We want to have access to both sides of the face. And just in case we also need an external approach, we'll also prep out the neck. So the whole prep should include bilateral face and neck. And whenever you're prepping around the face, best to avoid using scrub 'cause it will be very irritating to the eyes. Just use paint, and in this case I come right up to the, at least up to the level of the cheekbone so that we'll have full exposure without anything interfering our surgical field. And then now we're ready to drape. Alright, so we'll usually put blue scrunches on both sides of the neck and then we'll use straight piece like this. We will call them off around like a square. I do want to be able to see the neckline in case we have to go externally. Okay. So then we'll secure these. Okay, alright. Do you have a split drape? Lovely. Okay. Put it right up to here. Now that go straight down, the head drape please. Perfect. Goes right here. Okay, let's do timeout. We are doing RF of mandible, bilateral maxillomandibular fixation, risk of fire high, any antibiotics? Great. Can I get a tulip retractor? Just for occlusion.
So we're gonna start by putting a tulip retractor. You have a Frazier suction? You see that patient already has maybe even a missing tooth here. So some injuries and very gross malocclusion - irrigate. Stop, hm mm. Just an open fracture with the gingiva disrupted right where the fracture is present. So we'll first begin with the approach here. We're gonna see the nerve right in this location. I want to preserve it. And also I'm thinking about how we're gonna close this mucosa later. Can I get a DeBakey. There's bone. I'm gonna remove it so that we don't have an airway foreign body later. I'm not sure what this is. Might be... Might be missing teeth. Yeah, hmm. There might be teeth broken out. Yeah. So we're just trying to figure out how we're gonna close this later. This has to be closed in a watertight fashion. Do you have number nine, please? Just want to investigate this area before we commit to any particular incision. Suction that out please, there's more bone. I'm gonna remove all these debris because these are potential for airway foreign body. Yeah, I think her canine is broke. The canine is completely broken off. Makes me wonder if this is the canine. Suction for me. Yeah. That's her tooth root, right there. Hmm. It's a broken tooth. The roots are obviously disrupted. Also look like there might be old dental caries here. Can I have some irrigation? Yeah. So generally if the root is broken like this, we want to remove it because the dead tooth is a potential for infection in the future. I think that might be part of the tooth. The downside of removing it now is that it'll create a bone gap. So we'll have a harder time reducing it. It will lack stability because there'll be a bone gap. Another option is just plate it and then construct it in a separate situation. So looking at that, I think the, let me get a Bovie.
CHAPTER 3
We are gonna make an incision but I need to close this, meaning I need to figure out a way to close it in a watertight fashion later. We have enough mucosal stuff to close, along the lingual aspect. This might have to bend in to close this area. We make an incision here. Debating if I connect it or leave it separate. I'm gonna lean towards leaving it separate for now. Do you have iris scissors? Yeah look for our nerve as we go down. Should be right by the premolar. There it is. There's your nerve. Here's your nerve coming out, coming superficially. We're gonna preserve that. Yeah, go ahead, Bovie. I'm gonna cut away from this nerve, go ahead. Take this out. Do you have a retractor like a smaller one than that? Yeah. Yeah, will you hold this up for me? Because I wonder if it needs to be extracted. Which one? This canine, it's split right down the middle. I think this is the remaining part of the canine. There's a caries and stuff, so I think it's split off. But ask them if they would recommend leaving it or just extracting it. So there's your nerve. We're gonna cut down here. We know the nerve is over on that side. Suction. I see the nerve. Nerve is coming and entering the skin there. Now that we know where the nerve is from the midline, I can go subperiosteal, come straight down. This is right where the fracture site is. Do you have any 1% lido with epi? Sure do. Notice that it's a little bit oozy, so in this case I'll go ahead and inject it to see if we can get better hemostasis as we perform the rest of the surgery. At this time I've asked our oral maxillofascial surgeon to come by and take a look at the teeth to see if they prefer to check it now or later. I can reduce it and plate it however they prefer. Patient most likely will need this extracted. Wanna see what their preference to do in terms of timing. Number nine, please. Now here we're gonna dissect all the way down through the inferior border. Number nine, please. We're gonna dissect all the way down to the subperiosteal tissue plane to the inferior border of the mandible here. For this type of fracture, I always like to see the inferior border because that's one of our visual reference that tells us we have adequate reduction or not, come in with the retractor. Do you have it going the other way? So my goal is to expose enough soft tissue and bones so that this retractor that I have with toe going the other way and hook under can actually help with the exposure as well as the reduction. So there's our fracture line. Let's put a plate here, another one here. Can I get a number nine. I saw them there come up, I want to see the foramen just to help me decide exactly where to put the plate there. Right there. Bovie. Yeah. I wonder, yep, that's fine. So there's your bone. And even though this fracture is only about a day old, there is already callous forming. I generally like to scrape all this, especially if it's an old fracture, as it will interfere with our reduction process. There's your nerve. The question is, is there enough for two holes on this side? So you want to expose the bone enough so that we can put at least two holes on both sides of the fractures. This is sort of how the bone should come together. Just wanna figure out this tooth situation. I have a feeling the response from oral surgery team might be too extract the tooth. Do we have a dental extraction set? We do. We made sure it was in the room. Can I look at it? Yeah. Looks like the tooth has split. Let me get a local while we wait. Unprotected needle. Okay. Needle coming in. Suction there, yeah suction suction. And then inject right where we're gonna make the incision. Just inject where the incision will be made. Just a couple millimeters away from the gingival sulcus and then I go subperiosteal, inject right down to the level of the bone. Okay, alright, come on out with that. You have a tulip back, please? Okay, let's see what you have. There should be a little sharp triangular pointy things. This thing? Yes, let me get that. I can use that. Alright, so I'm gonna see if I can wedge this in here. Wedge there. See if there's a wedge in there, sharp and pointy things. Here's another sharp and triangular one. That's it, yep. And I do wanna preserve the mucosa. But the tooth has to come out. Can I get number nine, please? Suction right here. There you go. There is the remaining mucosa. Can I see the triangular tool again? Best option is to use a drill.
So we're gonna start occluding this while we are waiting. This incision from here to here, you don't wanna make it too wide 'cause it actually will block your point of view. Then the nerve's gonna be right by the first and second premolar. Can I get a number - iris scissors, first? We should be behind the nerve. There is your nerve coming out right there. Right between the first and second premolar right there. Grab the Bovie. Okay, open this, right there. Just Bovie right there. Good. Once I know where the nerve is. Do you have a toe in retractor that I was using earlier? The residents aren't around right now, but they looked at the scan and they think you should probably just take it out. Yeah, right? From how it looks on the scan. Okay, I'll take it out. That's fine. Curve it back this way. Now cut right down. Here's your fracture right there. There's your nerve. Okay, now come out with this. Turn the head. Okay, there's your nerve. Okay, you have a longer toe in? And it's a 702 drill bit. Let me get a number nine retractor. I'm gonna use number nine. Suction. So this one you can already see the inferior border. I can see the fracture, that we are gonna advance forward. Find this other section of this fracture. Suction. Some irrigation in there, there's the fracture. One more retractor, that's good. Thank you. There is your fracture line. Gonna clean it, with a Bovie. The nerve is in front of us. Go down to the inferior border. Okay, number nine, again. Thank you. Iris back, please, iris scissors. I have to dissect this nerve out because I need to see the superior border. There is your nerve right there, coming out. Bovie. Number nine, please. You have the one going the other way? The long toe out? You can see where the fracture is. I'd like to see both ends and also like to see where the nerve comes out. So we know how much room there is for the plates to sit. The nerve is being swept forward. Still have not seen the foramen. All right, so we're... The nerve is in here. Have more than enough exposure. Okay, hold on with this. Hold this. Don't block my vision. I wanted to see that nerve for sure. It's gonna be more anterior, can this wrench come up? I just want see the whole stump come out there. There it is. Yeah, we're far away from the nerve. Can I get some irrigation, please. Irrigations please. Okay, let me know when that drill bit, oh you got it. Your drill will be ready. Alright. And does that look like the side cutter that you... Okay, great. Yeah. Okay, let me see the tulip back, please. Okay, come on on with this.
CHAPTER 4
Okay, so the first step right now we got everything exposed. Now because the tooth is completely broken at the root level, the best idea is to remove the whole thing because the dead root will get infected. Number nine, please. Let's do that because the edge we had left it has split away. Yeah, we have to make the incision with understanding how we're gonna curve it. At this point, we will remove this tooth that's obviously broken off. It's very impacted, so it's not coming out. Look like there's some carries on the back in this location. Grab the irrigation. So this is a side cutting burr. Drill right into this. Hold on, too big. I'm gonna cut this pieces off. Okay. A little bit more, yep. Just gonna drill right into this area. Make sure all the remaining tooth root is gone. Gotta make sure we don't disrupt the tooth that the bases touch. Hmm, irrigate. Yeah it looks good to me. I think there might be a little bit of tooth. Number nine, please. I just make sure there's no remaining tooth on this side. Maybe a hint of it left right there. Oh yeah, I think there's nothing in here. I think the tooth already came up from this side. Just smooth it out. Okay good, so the tooth is gone. Number nine, please. So that now the chance of this getting infected is significantly reduced. Suction, suction. Come on out, yep. I think there's still tooth left in there. Tooth left in there. Yep, there's tooth left in there. Yeah. There we go. Hm, yeah. That's better. Now there's callous formation since the accident. Take this back. Okay. I just wanna make sure all the tooth is gone. The DeBakey, please. Hold on. So the tooth is good on that side.
CHAPTER 5
We are next gonna put her back into, proper occlusion. Is our next step. Now to do that we're gonna do maxillomandibular fixation. So the next step is we are gonna do maxillomandibular fixation here. Can I get the IMF screws? And this bite, let me do eight, please. So by doing so, we will put her back into proper occlusion. So that kind of look like premorbid occlusion. Thank you. So we are gonna secure probably one on this side, one on this side. How many are we gonna use? Maybe one on this side. Maybe four to six. Okay. That's an eight. Yeah. When you fix this, you wanna make sure you do not hit the tooth roots. I'm aiming for space in between the tooth roots. That is too close. It's not secured properly. Suction right here. Go right in there. I wanna make sure we do not hit the tooth roots by assuming there's twice to the root height, twice as the height of the crown. One more, please. So we're gonna put next screw adjacent or on the maxillary counterpart of that, that will bring her into proper occlusion. The maxilla, if you go too high, it'll be anterior maxillary sinus wall bone, which is super thin. So I wanna catch the thicker part of the alveolar bone, if possible. I am using this as a temporary reduction. If I were to leave this patient in MMF, which I typically do not for non-comminuted fracture like this. But if I were to leave long term, four to six weeks of MMF, I would recommend using arch bar type of MMF because these screws have a tendency to come out and there's a potential for it to be an airway foreign body. So it's fine for intra-op but not, I prefer not to use them for long term. But these screws can come out is the issue. Center incisors there, go right between the tooth roots. You can see that central segment is completely mobile. So that will go to this one. Now this back one, see where the bone is. Get some irrigation. Do you have a long pull out? And do you have one more long toe in? Hook this along the side of your border, then sideways. Okay, hold that please. Okay. I can see the fracture down there. Okay. I think they need to line up. Yep that and that lines up. It's how it looks to me. Come on out with this for a second, yep. Telescoped in, this and this needs to overlap. Yeah. So that's sort of how it should fit. Okay, alright. So we will want to secure one little bit more posteriorly. Be nice to have one more on this, but there's not much bone left on the posterior segment. Okay, can you get those wires? Gonna start with this segment because everything is so loose. Okay. Yep. So these wires line up with the slot, the screws, the screwdriver, how it engages. This crisscross lines up with the wire holes. I'm gonna first tighten this so you can kind of pull on it first. Make sure there's no significant laxity but as I'm twisting I'm not pulling on the wire 'cause it could snap. These wires are sharp, so you gotta be mindful of that. You don't want to get sharp injuries. I'm looking at this here. Irrigation, please. Yeah. Looks like we're missing a little bit of... Go on, on this side. I think this is that cortical bone that was, we're seeing, please save that. Although I don't think that's very usable. That's the outer cortex bone. So, good contact up here, superiorly. Inferior looks okay, so there's decent bone here. You could make the argument to put a recon bar. There's a little bit of gap, I think that's a little bit excessive. So in this case, this person is fairly young, 21-year-old. So I think they will do fine with just the regular mini plates. I think it would be okay. Might want to use a six-hole plate instead of four-hole plates. Okay, so that looks good. Can I get a wire cutter? Here is this back. Can I get a needle driver? So I always wanna, think this is a little bit long. Can I get the wire cutter back, please? These are potential for sharp injuries. So I grab it, I'm gonna twist it, I'm gonna pinch it and make sure it points away from us so it does not come back and get us. Okay, let's see this side. The goal is to get the teeth lined up. Because teeth are very sensitive to malocclusion, in the sense that even if you have a floss stuck between your teeth, pin number nine, please, your body can tell that there's floss stuck there. So even a little bit of gap will bother them since that sensation of malocclusion will be bothersome. So can you suction right there? Okay, good. Okay, pretty happy with that. Let's do wires again. Do one more set of wires. Front to back. Give it a little bit of a tug. Wire cutter. Twist it. Now when you're tightening it, don't pull 'cause it'll snap. Okay, let's cut it right below me. Yep, go ahead. Put your wire down. Sarps down. I'm gonna grab it, twist it and then pinch it. Make sure it's pointing away from our gloves.
CHAPTER 6
Okay, so the key to stabilizing this, just start with the easier one and go to the harder one. And in this case this posterior body fracture is gonna be harder of the two. So we're gonna start with this one. The reason why you want to do the easier one first is if you have an error, that will compound. So you always wanna get your first reduction and subsequent ones to be as close to perfection as you can. So let's see the toe out retractors. There it is. What is this? What's the name of this? That's reduction forceps. Just reduction forceps, okay. So I use this and then, so we'll use this to reduce it. You can use a bone reduction forceps like this or like this. You don't want to put it this way 'cause it's gonna block all of our plating. So I want to put it like this. Awesome. And the other thing I might do here, as I'm having a hard time seeing, just gonna extend the incision. Just straight down. The nerves are well away from us. Number nine elevators, coming down. You have a toe out retractor, please? That's the long one, you want shorter? Get one a little bit shorter than that, please. Okay, there's the midsize. That, we'll see if you can get the tulip in. But normally we get this out but that actually looks pretty reasonable. Can I get an irrigation? You can see there's a fair amount of gap still. Okay. Here you can see the inferior alveolar nerve coming out. Here's your gap. Before we move forward, I'll make sure that the teeth are well aligned with good contact of where this sits bilaterally. This piece we will worry about later, but at least in the front it looks good. And we are gonna now focus on where we're gonna put the plates. And so I'll probably put a plate here, another plate here. The top plates, I'll use monocortical to avoid the tooth roots. Lower one, you can go bicortical if you like. I'll always like to use all my screws to be locking screws. That way if there's any bit of issue with plaque adaptation, it will compensate and still provide good stability. So first just say we're gonna put the plate here. We might put a plate up here. And the question is, where can I safely drill. The tooth root might come down to about this area. So I wanna make sure we're not close to the tooth roots. And this bone clamp we can remove it after the first plate goes in. Use number nine to kind of fulcrum and get it into right alignment. And we are gonna fine tune that in a second with this bone clamp. So my thought is get it reduced with the bone clamp and then put a plate on and then we'll remove the bone clamp. So I'm gonna be liberal with where I'm gonna put this, generally nice to just put it where it won't be in our way. So I'm gonna put it about - we want to be sufficiently away so we can close this gap. I see a gap here so I might put it right here. Okay. And then we're, don't want to drill next to the nerve. So drill about here. Irrigation. Irrigate. Okay, you got the bone clamp? Let's say you wanna put it towards the right direction here. One goes in on that side, the other one goes on this side. I can wiggle this and kind of get it into the right alignment. Okay. Looking better. Okay, that looks pretty good to me. Irrigation again. So that reduces it to a tighter alignment. Checking the inferior border - suction. All the way down there. So make sure the inferior border gets lined up. Hold this like so. That's pretty good. Okay. Yeah, looks good. So the next thing is we will proceed with the four-hole plate for this. The bone on both sides of the fracture line is very healthy looking. There's good bone stock. So let me use a, yeah this one with a little bridge. Are you doing inferior first? Yep. - Yeah, so in this case the parasymphysis, biomechanically speaking, the inferior border is where it would splay. So the inferior plate is the more important one. Some authors, some surgeons might prefer to use thicker just a single thicker plate here, that's fine too. In this case I'm gonna just use two small mini plates. It's pretty adequate. So in this case I'm using a rainbow, long bicortical screws is probably what I'll end up using. The first two screws are the most important. Irrigation. I wanna make sure - can I see number nine for a second? I wanna make sure that posterior hole, you have enough bone there to secure. That looks good. Okay, screw. Gonna start drilling. That's fine, irrigate, irrigate. Okay so as I'm drilling, I'm feeling for first pop is the inner cortex. That's the second pop, that's the second one. That was inner cortex. Can I see the - do you have a screw depth gauge? I'll just measure one just to kind of give us an idea as to how deep this is. But I'll generally use about eights, eights or tens in this area along the inferior border. So there's a little hook. The idea is you put it through the hole and you catch it, the backside side, you push it down and it says 10. Can I get a 10 locking please? Yep, 10 locking. Alright, confirm with 2.0 10 locking. Lovely goes in. Now this first one, I'm not gonna tighten it all the way, I'm just going to secure it so that it partially engaged. This allows me to move my plate in the second hole, and this is really the key screw here. So then I make sure that we're happy with this alignment. This alignment looks good on both sides. Next hole. And when you do this, you wanna make sure you don't cut on the lip. This drill can slice through the lip. Going perpendicular to the bone surface. First pop, second pop. Can I get a 10-millimeter screws? So 10? Yep. So the locking screws has threads right there. That's what will lock onto the plate, give us extra stability. If there's any bone gap from the plate to the plate, we'll stabilize it. With non-locking screws, you won't have that luxury. You have to be perfectly adapted to the plate. So these locking screws, yes they cost more but I think they save a lot of time in the OR and I think they just provide superior stability. So there we go. So I'm gonna just take this off 'cause we, I'm pretty certain that that was enough. So we are then gonna proceed with the rest of the drilling and screw placement. Irrigation. This back one, this is the one that's a little bit harder. There you go. Coming at a little bit of an angle here again be another advantage of this is angle, when you drill this at an angle, depending on the manufacturer, it allows for 30 degrees of movement or angulation. Just still the screws. Still provide it should be able to still lock on even if it doesn't come in at a perfect angulation. That feels solid. One more please, one more drill. Irrigation. Going down perpendicular to the bone surface. First pop, second pop. 10 millimeter. And if you're really worried you can measure all the screw length. But they'll generally not deviate much in someone like this with teeth. So usually not necessary. In this case, screw likely is caught up by bone dust. In that case you're gonna come out to or come out once, go forward, come out once, go forward, come out once go forward that will just clear the bone dust so that it can engage to the plate properly. All right, so that was our first plate. Generally I would prefer to put two. That's showing good signs of reduction there. Can I see another four-hole, maybe without a bridge this time, please? Thank you, thank you. You're welcome. Alright so this we're lucky in the sense that this area, we're right in front of the nerve, we're not near the nerve. The nerve is there. You need to sometimes go above it or right below it. But in this case we have the luxury of not worrying about that too much. It looks like the front and the back plate needs to be bent down a little bit. Can I get a plate bender? So these mini plates, you could potentially bend it with your fingers but we use a small plate bender like this 'cause that last plate, last plate screw holes needs to be bent down just a teeny bit. And it's generally better to just do one at a time 'cause there's a general tendency is to bend it too much and then it doesn't quite fit. That looks better. Now the superior plate, I wanna make sure I don't go into that hole there. Oops sorry. Right there and right there. Yeah, that's good. Okay, can I get the drill back, please? So these, I'm gonna go monocortical. These are the smaller ones. Great, thank you. What are the - is this five stop, or what are the? That's a five stop. Oh, lovely. The five millimeter, yep. There's your one, two going in. Again, partly, part of the way in. And then we move this plate over. Yep, right there. There you go. Leave it to where I wanted to. And for the superior plate I like to use either four- or five-millimeter screws. Especially if I'm getting really close to the tooth root, so I wanna make sure I don't put it through the tooth roots. Tighten the first one, then go back, tighten the second one. Feels solid. Then these holes look very well adapted already. So point it perpendicular to the bone. Irrigation, please. Hm, mm. Let it start and then come down. Okay. One more, irrigation, hm mm. It's okay, all right. Screw. Alright, keep it on at the angle where I'm at on this side. Do you have another screw? Yep, and here's another five. Yep. Here, go down. Yep, go all the way down. A little bit more. That's it, perfect. So we're good on this side.
So we're gonna start looking at this section. This is that posterior body segment that was quite telescoped, but you can see that the - you guys see number nine, please? Yeah you can see this part. See the outer cortex part that had greensticked. That looks like... It's kind of a greenstick fracture right there. Yeah, I think it's properly reduced... So part of it might be the greenstick fracture that's giving us the problem. That's better. I kind of like that. Irrigation. And the teeth is now in posterior, and push up like that. Yeah so it needs to be like this while we're plating. This area also needs to be pushed a little bit more. You got a long toe out? I'm sorry. I'll turn her head. Ideally, like to see the inferior border. Let me see one more toe in retractor. Tough to see an angled fracture. Let me see this way, with toe out. You have a Bovie? Then if your border needs to be looked at more closely here. Trying to avoid opening this. That looks better. I think that's how it should be, just like that. Okay. It's a little bit tricky. The back one needs to go all the way back here. Come down. The upper one's straightforward. The upper one is okay, question in mind that I have is do I do two separate plates or one hybrid fused plate. But generally we'll do two plates but this is a little bit of unusual fracture. Okay, now the other thing I noticed is a little bit more exposure anteriorly. With the body there's a cordial movement where the bone is instead of splaying superiorly or inferiorly, it has more of a side to side movement. Okay, so that's kind of how I want it to be when I reduce this. Teeth are not quite touching on the back side, I think, yeah, that would be good. Like so, just like so. What I'm noticing is little bit of open bite posteriorly. I might put little bit more - another IMF screws. Pull it up. Let me get two more IMF screws, please? The one that we were using before? And one option is to use this type of plating system. This is what I typically use on the angle area. This might be an option. Give us a fair amount of flexibility. That might be an option. Okay, so we'll first do this 'cause I don't want this area to stay open. If I really want I can put another one back there but it's gonna be hard to reach back there so I'm not going to try to attempt to do that. But that is another option. It's just that it's gonna be limited space. Go right here. Pull this. Can I get the wires next please? Yep. Awesome. That's it. Pull it through. So by doing that I can see that the back segment is closing down, which is ideal to avoid open bite deformity. Yeah, do you have the wires again? The wire cutter rather. Yeah. Hm, yep. Do you have one more blue towel? Point this way, close it. You have stapler or, this one's good, thank you. Okay and then now we're gonna start plating this. This is a lot more stable posterior. Actually the posterior segment also looks very stable. Question here is, I should be able to plate all this through the mouth. Another option is go transbuccal here. Let's see that nerve one more time. There is a way out here, yep, that's the foramen right here in line with the premolars. So we're well away from that. So the plate configuration is the next decision that we have to decide on. It looks fairly well reduced, actually. Just releasing a bit of it more posteriorly for us to get better exposure. Can I see some irrigation? So let me see, do I want a bone clamp here? Not bad. Okay, I know I can get it tighter with the reduction forceps but it will interfere with all the rest of the plating. It's generally in the angle area. It's very hard to place a reduction forceps. It's actually not bad the way it's right now. Teeth touching, posteriorly. What I might do is just go ahead and put a two-tiered plate on. I saved this plate that you took out. Thank you, Kelly. Okay. You are awesome. Let me see if this is the right type of plate, for our purpose here. The nice thing about it is once it's engaged, then they all go in. I think I might remove this one. Yeah, I might remove that one. The very front two holes. Okay, can I get a plate cutter, please? Plate cutter. Thank you. So I'm gonna just take this one off because I think it's too long. You see this plate that he used? Okay, I just wanna make sure you got the numbers. Thank you sir. These plates are nice, but in the angle, there's a tendency for the posterior and the anterior one to fall off the bone. I'm sorry. Do you need the trocar? I might use a trocar. I'm gonna start without it and then I'll most likely have to. I'm thinking something like this. This one might be really close to that nerve. Where is that nerve? Right there. Yeah, this has to be come out 'cause the nerve is lower. Can I get this? Yeah. Alright. Okay so that might be what we need. There we go, that looks pretty good. Okay. Okay, so I'm gonna start with superior border plates. Get this secured where you want it to. Let me see number nine. Suction right here. That's not bad. Good. I want this one to catch the middle piece. Okay, and then the nerve is right here. So, I don't know exactly which way the nerve is traveling, but I'm gonna assume the nerve is deep to this location. Just like before, we'll use a... Do you have a four-millimeter screws for when I start? But I can use a rainbow drill for all of these. So I'm gonna start by securing the top plates or top screw placement. Okay, I think - get the suction, irrigation. I gotta watch the lip here 'cause nothing's protecting it. Don't move this, don't drop. Don't worry about the suction. Just irrigate. I don't know if you're... You have a four? Yep, got a four ready. Four, please. The 2.0 locking 4. Great. Let's get this started. I'm gonna check for our screw placement and everything. This next hole is super critical. Making sure all the teeth are touching superiorly along the occlusion plane. Right there is good. Number nine, please. Position it so that one, it'll catch this middle piece, but two also wanna make sure it doesn't fall off the bone posteriorly. Again, when you're putting these screws on, these type of screws on for this plate, just go to the easiest one to get it secured where you want it and then, okay that's enough. Suction. Okay, the fourth. So once you're secure, is now secure, with these two screws, things are much more manageable. But these two screws are the key component of this reduction and fixation. The teeth look good. So I lock on this one. Okay, good. Okay. So that looks pretty good. One that's a little bit iffy. You stay right there. Can I see a...? Okay, drill. Watch the lip. Yep. That's good. Can I get eight on this one? Yep, suction. Immediately inferior to the middle piece that's essentially making into a three piece type of fracture here. Yeah, it's outer cortex only, but it'd be nice to catch that one as well. Using locking screws here again, securing this in place. Okay, suction. I might switch over to a trocar, next, but for these back ones - irrigation. Irrigate, irrigate, irrigate. This back one, this back one, I can't really get a good angle on that. These upper one's probably not a big problem but this one needs a transbuccal trocar. I'll need the transbuccal trocar, Kevin. It's right here. Oh, you guys are awesome. Look at you guys. Ready for you. You guys are a step ahead of me. So, we're gonna use this to secure this in place. Generally you want this pointing up towards you. You don't want it like this 'cause this is what allows you to see the screws and drills coming in and out. It's gonna go through the cheek to do that through a small opening. And then let me see this part. So this part, the mistake a lot of people make is, instead of just hovering right where the viewing angle window is, people tendency to do this. In that case you will end up with a situation where, number nine, please. Number nine for a second. You have a lot of - this is all wasted space that you're not gonna be able to use and it will interfere with manipulability. So we are gonna just hub it once it's in like this we'll just hub it like so, this way, like so, so that this way you're only wasting that amount of space. So when you're in a space tight like that, that makes a huge difference. And also the other mistake people make is putting it like this but now you're completely blocking your view, so it's suppose to be this way. Okay, it's a little bit loose. Can I get an empty screwdriver? It's a little bit loose, so we'll tighten that first. There we go. It's better, better, better. I do worry about the cheek. So we'll do all that under the transbuccal system trocar. Here, I'm guesstimating. These are the ones you want to use this system for. I'll go about halfway in line with this. So I'm gonna point to my tonsil, tip right to the middle of that. To here. Okay, turn the head please. You have a 15 blade? Actually, let me get a marking pen first. In this case, what we're trying to avoid, patient's mandible here, like so. Patient's gonna have marginal mandibular nerve that comes out way back here from the parotid. They'll usually come at least two finger breadths is sort of the general statement, or general assumption that we have. So, but it could be, you know, buccal branch could be kind of coming like this, so it could be anywhere in this area. So we wanna, we're doing it so that we can protect this nerve and I think where it is should be well away. So this is kind of the area that I'm pointing to, confirming my positioning in here. Yeah, that looks pretty good. A little - okay. 15 Blade. Make a little skin incision. I need about two- to three-millimeter skin incision just going through skin here. Let me get a mosquito next, please. And then I go in with this. And this is a blunt tip instrument. It's not gonna cut the nerve. Gently spread. And then pop into the mouth. So there's your instrument. Okay. So the next step is this. We'll have that pointing up towards us. Go through with this. Find the same tunnel that we created. Okay, now can I see that? Yep, perfect. Now I'll place this, again just past the viewing window. You don't want to choke up like that 'cause then now I can't move this at all. So you want to just hub it, hub that viewing window. And then this screw needs to be super duper tight 'cause if it comes apart you gotta do all this over again. So really crank on this, make sure it's super tight. And then now this piece comes out and now I'm able to move it around where I need to. Now I wanna, this handle helps me get leverage on this to move it to where I want this to go. So I'm gonna swing this around. In this case his shoulder is in the place. Okay, so that's sort of what we got going on. At the first part of this, I'm going to secure the middle segment. This one is a little bit unreliable in terms of where it's sitting. I want to secure it while it's still in place. Irrigate. Okay, can I get an eight? Eight is here. Huh? You guys are flying. I mean the tooth part was the hardest part. So, once that's been sorted out. Okay. Drill back, please. Can I see a Bovie? We have enough mucosa to close everything so not too worried about that. Can you wipe the suction, please? Thank you. That's good. So then I'm gonna, it's gonna be really hard to get this lined up like that. So I'd rather pull it away and get it in line like this so that my drill bit is in the direction I want it to go. Let me see - do you have a five? Okay, I'll get a five. And part of it's, I don't know exactly where the nerve is traveling so I'm gonna use monocortical for these, even the inferior ones. We'll use locking screws for all these and I'm keeping this steady, so that I don't have to move the direction that I'm holding this so that the screw lines up, right when it's ready to turn to the plate. Okay, the rest of these are pretty piece of cake. Okay, monocorticol on these. Right by the teeth and the nerve. Okay, let me get a four. That's a four there. Good, thank you. Let's see this one. Okay, one more four, again this screw might be in line with the nerve, so you wanna minimize going too deep on these. Confirm four locking. Thank you. Another screw going in, monocortical that's locking. Okay, we'll turn the head over a little bit more here. Okay, back. I think I can throw this on here? Like so, hm mm. Little suction. Now this one is bicortical. Can I get the eight that you had earlier? That's good. This one I feel pretty comfortable putting in bicortical just 'cause it seems well away from the tooth roots and the nerve where they would be traveling. Yes, sometimes the magnet will make it move. Yeah, it was when it hit that instrument. Okay. Now we go bicortical here. The nerve is very close to this particular location. A second. Hold that like so. Looks like I kind of come in at a little bit of an angle, get as perpendicular as I can. Do you have a four? I do. Lovely. I do. That's good. Okay. And then, now do you have a heavy needle driver? I'm noticing that this plate is lifting off the bone a little bit. Which in theory doesn't matter if you're using a locking screws, I wanna just bend it down with the needle driver because these are mini plates that will bend like that. So that will adapt it better to the plate. Better to have like essentially no gap between the bone and the plate itself. Let me get another four, please. Four millimeter. Five's good. There we go, this is our last screw. Okay. Let me just see one more thing. Number nine, please. Do you have a three? Three millimeters? What's the shortest one do you have? We have a four bone... Okay. Let me - I'll take a four, yeah that's fine. This is a slightly larger diameter, 2.3-millimeter diameter screws. So if the first screw stripped, then you could always use larger diameter screws, 'cause now the bone hole has been widened by the screw. That looks really good. Happy with all that. Good bone alignment. The teeth looks okay. Okay, let me see the empty screwdriver. We will disengage. Take this out, take this out. Thank you. Thank you so much. Let me just take a look one more time at this fracture, it was a little bit of a harder than usual because, I got this one, I got this one. Because it broke with the odd triangular piece at the bottom but that looked like it came together pretty nicely. That looks pretty good. Okay. So in this case, we use a transbuccal trocar. I almost always use it for subcondylar and the angle but in this case 'cause it's so posterior, for these sets of screws in the back, we have to use the transbuccal trocar system.
CHAPTER 7
So now, we are gonna release her out of the MMF and I'll generally prefer not to do rigid MMF just 'cause there's a lot of compliancy issues with the patients cutting them out. And also there's always concern of, with any concern for vomiting and airway concerns, best to not leave the patient in rigid MMF. Can I get a wire cutter? Yes, sir. And let me get a like clamp to get these out. So we'll cut her out of the wires. That's good. Yeah, just don't lose the wires. Get more please, there's sharp wires there. Thank you very much. More sharps, coming back to ya. Appreciate it. You want to make sure you don't lose these. These can become airway foreign bodies. Pull that straight, okay. Now can I get empty screwdriver? Okay. So in this case, we use the Stryker system for the plating. Other manufacturer may have similar type of ways to perform MFF and plates. And it's always nice to have a hardware rep that's very knowledgeable who can help us with this case going very smoothly. Okay we'll get these out and you have to get these posterior, we'll just get the retractors out, grab the screw with my instrument. And for an incision we'll need a 3-0 Victryl pops, also need a 5-0 fast. Thank you. Okay get this out, okay awesome. Okay, thank you.
CHAPTER 8
Just wanna make sure we got good occlusion after doing all that work. That looks really good. Irrigation, please. You see this area touches. This area touches here nicely too. So her occlusion has been restored. And what I mean by that is it's premorbid, we've assessed the line, we got that teeth here that was broken, try to minimize risk for infection.
CHAPTER 9
So now the next challenge we have is closing. This has to be watertight. Because if it doesn't, she'll get an infection. See there's actually a mucosal laceration. Let's get some irrigation. You have a paint stick? Can I get some iodine paint? Either the stick or just off the kit is fine. I'm just gonna irrigate with the iodine paint. This one looks good too. The first party is closing this in a watertight fashion. And you always wanna start closing at the hardest one, which normally it would be this section but in this case this is gonna be, one of the more challenging areas to close. From the - go ahead and do that. Okay. Oh yeah, let's do this. Thanks for reminding me. There's that. Thank you. Do one more. I do this to minimize risk of infection. This should be good. Thank you, irrigation, please. Get all this out. Let me see a sweetheart, please. Then I'll take a Gerald or some sort of two pickups. Yeah, can you hold it like this. Tooth Gerald. Lovely. Can I get a 3 Vicryl pops? Did you want this sent, this bone? Nah, just garbage it. We can throw that out. Okay, awesome. Thank you. 3-0 Pop. Thank you. Do you have like a longer needle driver? Yeah, I'll get that on there for ya. The next one will be on the longer. Great, awesome. Gonna close this back portion. Let me close this right here. Needle down. Okay you can leave these on to cut at the end. Can I get suture scissors? Just leave it, we'll just cut 'em all at the end. More please? Is that driver okay, or do you want... Yeah, this is perfect, thank you. We want to make sure this tooth socket, this lacerated mucosa, is closed in a watertight fashion. More please. So, we do have enough mucosa, just they're all lacerated, but these instances where you don't have mucosa, you need to cover up the, definitely the bone, especially the hardware, 'cause if you do not, it will definitely get infected. In this case, right here, I'm gonna go around this tooth. This kind of helps me make the mucosa a little bit more reliable by catching more tissue just coming across like so. All right, you have a scissors? Let's cut that. Go ahead and cut it. Yep. Just relax on this suture, and come up. Okay, relax on that, yep. Alright so then this part, so for... I don't usually do deep sutures, I know there's a lot of authors talk about that but I generally would just do, sutures along the edges, meaning not try to re-suspend everything back up. Dr. Lee, thank you for a nice case. Oh, thank you, Kelly. Yeah you're awesome, you did a great job. Thank you so much. But in this case I will suspend it, suspend some of these deeper structures. More. Okay now, just relax on that, yeah that's better. There's your nerve. Let's continue... So preserved. Actually don't want to catch the nerve with the suture by accident. And this patient did have paresthesia, numbness involving the, more of the right of the midline chin area. likely from the inferior alveolar nerve being irritated from this fracture. So I do warn them they'll most likely have worse numbness if anything. But I would expect a lot of that to resolve with time. Let them know that it might not come back a hundred percent. Especially if they have preexisting numbness. Going across that trifurcation. And angle it, with a wide tissue-spanning so that we can catch more tissue in case they fall apart. And I do stress the importance of for this patient to stay non-chewing diet for about six weeks, has to be strictly soft diet for six weeks. Thank you Kelly. Bye. Appreciate it. Okay, sweetheart back, please. I got it. Alright so we're gonna close this back one and this is usually the ones that start first just because generally most posterior is more difficult. Now that I see a mucosal tear all the way in the back, Just get that closed. I see that the gingiva is pulling away from the tooth and we'll resuspend everything. Sutures. I'll start right here, right by the tooth. Yep. Relax. Right there, suction. Can I see the P/D tonsil, Yankauer, the small. This is a hard throw, just the angle of it. Alright suction. P/D tonsil. Hold this like so. You don't have it? Don't worry about it if you don't have it, get used to operating with what you have and keep moving. So I prefer Frazier suction when we're right on the bone. If we're near soft tissue that can suck into the suction tip, then I prefer to use pediatric Yankauer, metal. Stop, move, there is the needle. Okay, good. That's a pretty good bite there. Okay, suction, or scissors. Yep, yep. These scissors? Like a little bent for this, like so. Okay more sutures. Going very posterior. Again the more posterior you go, the more difficult. In this case, I do worry about it coming apart so I'm gonna go around the tooth most likely helps me minimize the risk of it falling apart. For this suture, I'm gonna be going through the teeth here. And then come back and then go under the mucosa again. Come out submucosally and then come back submucosally out here, and then tie this to the previous suture that we started on. We'll tie this to this and then this will really prevent that mucosa from pulling apart. Especially when it's pulled apart like this from the initial accident. It's nice to have strong suture to secure on the tooth, hold the mucosa from falling apart. You have different scissors, that cuts? Alright, thanks. Okay, I'm just gonna put one more suture back here. Section out in the back. Yeah, that's good. And can we get an NG tube from you guys? Yep. Awesome. Scissors. Okay, more sutures for in the back. This necessitates going in this direction. Needle. Okay, this mucosa looks a little bit unreliable. I'm gonna loop around the tooth. Come back through. Might even come back, actually let's go up here. Put that under. I got some mucosa again. And this SH needle is working okay, but if you have a very tight corner, you can use a UR-6 needle, which has a tighter curve and is more rigid. So that's the preferred option to use in a very tight spot. Usually comes with like a 2-0 Vicryl. Okay. Okay that's good and tight. More please. I'm gonna put one right there. This one's gonna connect the mucosal laceration securely, with the tissue that looks a bit unreliable. Okay. I think that's it, let me just make sure there's nothing. Yep, suction here. Go back in. Make sure all this area gets secured properly. Now that - so that looks good. Okay. I think it's perfect. Do you have Dermabond, please. So I like to help it seal up. We are gonna apply the dermabond. I know it's usually used externally, but I typically will also use it intraorally and I do think it helps it minimize the risk of wound dehiscence, and actually will provide a watertight seal. It just peels off about a week out so just let the patient know that you are gonna have a plastic-like thing. You have one more of these? They just peel off about a week out. I like to use it intraorally to help it seal. This provides one added layer of mucosal dehiscence protection. Let it dry and then, do you have a 5-0 fast, please? Close this area, we did a transbuccal trocar. Usually one or two sutures is all you need. Okay, we are gonna check for lip movement after this when she wakes up. Can I get one more Dermabond?
While we wait, we are going to, very important, suction out her stomach, 'cause if she vomits, then it could always be an airway concern, but I just - whatever blood she swallowed can be very irritating. Okay, suction. And she did vomit this morning from blood. This - what's up. This must be a new NG tube. Okay. Okay to come up on O2, doc? Oh yeah, one second. Let me just go down one more time. Okay, let me go through her mouth quickly. Disconnect the suction. Yeah. Okay, go ahead. Oh yeah. Suck while coming back up. Just leave it connected. We have that Dermabond whenever you're ready. Great, I'll take it in a second. Okay, good. So teeth looks fine. Everything is closed. And then Dermabond right here where we put this skin suture.
CHAPTER 10
Now that we have discussed the case, I'd like to also review postoperative scans. So here's your CT axial scan. Here is the parasymphysis site, showing good restoration and atomic relationship. Here's your monocortical screws, and here's your inferior bicortical screws. Now one thing that I'm not entirely sure about, is I do think there may be persistent canine tooth left on this opposite side. So for that reason, we'll have patient be seen by oral maxillofacial surgeons once the bone's fully fused for at least six to eight weeks. This may require formal extraction once the bone has fully fused. For the body site, it shows really good reduction. Here you can see the plate and screw placement with good alignment along the outer cortex and good alignment along the inner cortex. Next, we'll also review 3D reconstruction of this case. Here is your body site, and here is your parasymphysis that's been repaired. So that concludes our discussion. Thank you.
